| 入力電圧: | 3.0-3.4V | 発光効果: | 240 lm/w |
|---|---|---|---|
| 光束: | 240-280LM; 350-400LM | 力: | 3W、4W |
| 表示角度: | 120° | カラーレンダリングインデックス: | 70/80/90/95 |
| 動作温度: | -20-100℃ | 保管温度: | -20-80℃ |
| サイズ: | 3.5*3.5mm | 現在: | 700mA,1000mA |
| チップ素材: | インガン | 基板: | セラミック |
| チップサイズ: | R3.0MM | 光学的減衰: | 0.1％ |
| 製品の重量: | 0.01kg | ||
| ハイライト: | Sanan SMD3535 LED chip 3W white,ceramic substrate LED chip 4W,120° viewing angle SMD LED |
||
| Color Temperature (CCT) | 2700K (Soft Warm White), 3500K (Warm White), 4100K (Neutral White), 5000K (Daylight), 6000K (Daylight Alert) |
| Input Voltage | 3.0-3.4V |
| Warranty | 2-Year |
| Type | SMD LED |
| Support Dimmer | Yes |
| Lighting Solutions Service | Lighting and circuitry design, LitePro DLX layout, auto CAD layout |
| Luminous Efficacy | 240 lm/w |
| Lifespan | 2 years |
| Product Weight | 0.01 kg |
| Chip Material | INGAN |
| Emitting Color | White |
| Luminous Flux | 240-280LM; 350-400LM |
| Power | 3W, 4W |
| Viewing Angle | 120° |
| Color Rendering Index (Ra) | 70/80/90/95 |
| Operating Temperature | -20°C to 100°C |
| Storage Temperature | -20°C to 80°C |
| Substrate | Ceramic |
| Size | 3.5*3.5MM |
| Chip Brand | SANAN 55mil/SANAN 45mil |
We accept OEM and ODM service to customize any type of LED chip.
